Kaedra –for modular device

Characteristics Main range Kaedra product or component type Weatherproof enclosure enclosure type Enclosure for modular device accessories included with enclosure 1 wiring strap 1 marking kit 1 terminal block support 1 terminal block 8 holes mounting plate description Slotted Complementary enclosure mounting Surface number of 18 mm modules per row 12 total number of 18 mm modules 12 number of horizontal rows 1 electrical insulation class Class II Double insulation provided equipment 1 marking kit 1 wiring strap 1 terminal block 8 holes 1 terminal block support type of front cover Reversible Transparent power dissipation in W 24 W [In] rated current 63 A type of rail DIN number of pre-cutouts PG ISO 17 number of terminal blocks 1 with 8 outgoers distribution block outgoers 4 x 10 mm² 4 x 16 mm² locking options description Optional keylock enclosure material Self-extinguishing polymer width 340 mm height 280 mm depth 160 mm internal depth 88 mm colour Door: transparent green Enclosure: light grey (RAL 7035)
